2019 Scodix Ultra 101

No longer available

2019 Scodix Ultra 101


Foil technology Digital in-line with Scodix PAS™ foil technology

Foil roll width (min/max) 50-500 mm/1.97-19.68 in

Foil roll size Diameter: max 30 cm; Length: max 2,000 m; Core: 77 mm/3 in

Max number of simultaneous rolls Up to 4 rolls

Polymer layer thickness From 20 up to 90 microns

Substrate weight 135-675 gsm/6-30 points

Substrate thickness Up to 700 microns

Foil film type** Wide variety of industry standard hot/cold foil films

Substrates*** Offset, HP Indigo ElectroInk, plastics, laminated and

coated/uncoated substrates

Resolution Up to 2540 x 450 DPI

Variable Data Enhancement (VDE) PDF, optimized PDF, barcode system (optional)

Scodix RSP™ Technology 4 CCD camera system, RSP™ (Rotate, Scale, Position) algorithm,

automatic positioning, ± 100 micron image to image registration

Substrate loading sizes Min – L297 x W420 mm / 11.7 x 16.5 in

Max – L545 x W788 mm / 21.5 x 31 in

Printing image size Max – L748 x W504 mm / 29.4 x 19.8 in

Polymer tank system 1 polymer tank

Press dimensions (L x H x W) 7880 x 1790 x 1979 mm / 310.2 x 70.4 x 77.9 in

Press weight (net) 5300 kg / 11684 lbs.


ModelUltra 101
